Features of HDPE Pipe
· High corrosion resistance, resulting into a longer life
· High impact strength
· Extremely light weight and hence easy to handle
· High flexibility
· High abrasion resistance
· Excellent water hammer characteristic helps, sustaining surges
· Excellent flow characteristics leading to significant energysavings
·Shifting soils -no breakage
· Earthquake resistance
· No infiltration, helps maintaining the quality of fluids beingconveyed
· No trenches needed, resulting into easy and economicalinstallation
· High UV resistance to scaling and biological build up
·Allows fusion to eliminate leakages
Specification:
| PE100 | 0.4MPa | 0.5MPa | 0.6MPa | 0.8MPa | 1.0MPa | 1.25MPa | 1.6MPa | 2.0MPa | 2.5MPa | |
|---|---|---|---|---|---|---|---|---|---|---|
| Outside Diameter | PN4 | PN5 | PN6 | PN8 | PN10 | PN12.5 | PN16 | PN20 | PN25 | |
| SDR41 | SDR33 | SDR26 | SDR21 | SDR17 | SDR13.6 | SDR11 | SDR9 | SDR7.4 | ||
| Wall Thickness (en) | ||||||||||
| 20 | 1/2” | - | - | - | - | - | - | 2.0 | 2.3 | 3.0 |
| 25 | 3/4” | - | - | - | - | - | 2.0 | 2.3 | 3.0 | 3.5 |
| 32 | 1” | - | - | - | - | 2.0 | 2.4 | 3.0 | 3.6 | 4.4 |
| 40 | 1 1/4” | - | - | - | 2.0 | 2.4 | 3.0 | 3.7 | 4.5 | 5.5 |
| 50 | 1 1/2” | - | - | 2.0 | 2.4 | 3.0 | 3.7 | 4.6 | 5.6 | 6.9 |
| 63 | 2” | - | - | 2.5 | 3.0 | 3.8 | 4.7 | 5.8 | 7.1 | 8.6 |
| 75 | 2 1/2” | - | - | 2.9 | 3.6 | 4.5 | 5.6 | 6.8 | 8.4 | 10.3 |
| 90 | 3” | - | - | 3.5 | 4.3 | 5.4 | 6.7 | 8.2 | 10.1 | 12.3 |
| 110 | 4” | - | - | 4.2 | 5.3 | 6.6 | 8.1 | 10.0 | 12.3 | 15.1 |
| 125 | 5” | - | - | 4.8 | 6.0 | 7.4 | 9.2 | 11.4 | 14.0 | 17.1 |
| 140 | 5 1/2: | - | - | 5.4 | 6.7 | 8.3 | 10.3 | 12.7 | 15.7 | 19.2 |
| 160 | 6” | - | - | 6.2 | 7.7 | 9.5 | 11.8 | 14.6 | 17.9 | 21.9 |
| 180 | 6” | - | - | 6.9 | 8.6 | 10.7 | 13.3 | 16.4 | 20.1 | 24.6 |
| 200 | 8” | - | - | 7.7 | 9.6 | 11.9 | 14.7 | 18.2 | 22.4 | 27.4 |
| 225 | 8” | - | - | 8.6 | 10.8 | 13.4 | 16.6 | 20.5 | 25.2 | 30.8 |
| 250 | 10” | - | - | 9.6 | 11.9 | 14.8 | 18.4 | 22.7 | 27.9 | 34.2 |
| 280 | 10” | - | - | 10.7 | 13.4 | 16.6 | 20.6 | 25.4 | 31.3 | 38.3 |
| 315 | 12” | 8.6 | 9.7 | 12.1 | 15.0 | 18.7 | 23.2 | 28.6 | 35.2 | 43.1 |
| 355 | 14” | 9.7 | 10.9 | 13.6 | 16.9 | 21.1 | 26.1 | 32.2 | 39.7 | 48.5 |
| 400 | 16” | 9.8 | 12.3 | 15.3 | 19.1 | 23.7 | 29.4 | 36.3 | 44.7 | 54.7 |
| 450 | 18” | 11.0 | 13.8 | 17.2 | 21.5 | 26.7 | 33.1 | 40.9 | 50.3 | 61.5 |
| 500 | 20” | 12.3 | 15.3 | 19.1 | 23.9 | 29.7 | 36.8 | 45.4 | 55.8 | - |
| 560 | 22” | 13.7 | 17.2 | 21.4 | 26.7 | 33.2 | 41.2 | 50.8 | 62.5 | - |
| 630 | 24” | 15.4 | 19.3 | 24.1 | 30.0 | 37.4 | 46.3 | 57.2 | 70.3 | - |
| 710 | 28” | 17.4 | 21.8 | 27.2 | 33.9 | 42.1 | 52.2 | 64.5 | 79.3 | - |
| 800 | 32” | 19.6 | 24.5 | 30.6 | 38.1 | 47.4 | 58.8 | 72.6 | 89.3 | - |
| 900 | 36” | 22.0 | 27.6 | 34.4 | 42.9 | 53.3 | 66.2 | 81.7 | - | - |
| 1000 | 40” | 24.5 | 30.6 | 38.2 | 47.7 | 59.3 | 72.5 | 90.2 | - | - |
| 1200 | 48” | 29.4 | 36.7 | 45.9 | 57.2 | 67.9 | 88.2 | - | - | - |
| 1400 | 54” | 34.3 | 42.9 | 53.5 | 66.7 | 82.4 | 102.9 | - | - | - |
| 1600 | 64” | 39.2 | 49.0 | 61.2 | 76.2 | 94.1 | 117.6 | - | - | - |
| 1800 | 69.1 | 85.7 | 105.9 |
Standard: ISO4427, AS/NZS4130, DIN8074, GB/T13663-2000
